Today, we continue our exploration of multi-step time-series forecasting with torch. This post is the third in a series.
-
Initially, we covered basics of recurrent neural networks (RNNs), and trained a model to predict the very next value in a sequence. We also found we could forecast quite a few steps ahead by feeding back individual predictions in a loop.
-
Next, we built a model “natively” for multi-step prediction. A small multi-layer-perceptron (MLP) was used to project RNN output to several time points in the future.
Of both approaches, the latter was the more successful. But conceptually, it has an unsatisfying touch to it: When the MLP extrapolates and generates output for, say, ten consecutive points in time, there is no causal relation between those. (Imagine a weather forecast for ten days that never got updated.)
Now, we’d like to try something more intuitively appealing. The input is a sequence; the output is a sequence. In natural language processing (NLP), this type of task is very common: It’s exactly the kind of situation we see with machine translation or summarization.
Quite fittingly, the types of models employed to these ends are named sequence-to-sequence models (often abbreviated seq2seq). In a nutshell, they split up the task into two components: an encoding and a decoding part. The former is done just once per input-target pair. The latter is done in a loop, as in our first try. But the decoder has more information at its disposal: At each iteration, its processing is based on the previous prediction as well as previous state. That previous state will be the encoder’s when a loop is started, and its own ever thereafter.
Before discussing the model in detail, we need to adapt our data input mechanism.
We continue working with vic_elec , provided by tsibbledata.
Again, the dataset definition in the current post looks a bit different from the way it did before; it’s the shape of the target that differs. This time, y equals x, shifted to the left by one.
The reason we do this is owed to the way we are going to train the network. With seq2seq, people often use a technique called “teacher forcing” where, instead of feeding back its own prediction into the decoder module, you pass it the value it should have predicted. To be clear, this is done during training only, and to a configurable degree.
library(torch)
library(tidyverse)
library(tsibble)
library(tsibbledata)
library(lubridate)
library(fable)
library(zeallot)
n_timesteps 7 * 24 * 2
n_forecast n_timesteps
vic_elec_get_year function(year, month = NULL) {
vic_elec %>%
filter(year(Date) == year, month(Date) == if (is.null(month)) month(Date) else month) %>%
as_tibble() %>%
select(Demand)
}
elec_train vic_elec_get_year(2012) %>% as.matrix()
elec_valid vic_elec_get_year(2013) %>% as.matrix()
elec_test vic_elec_get_year(2014, 1) %>% as.matrix()
train_mean mean(elec_train)
train_sd sd(elec_train)
elec_dataset dataset(
name = "elec_dataset",
initialize = function(x, n_timesteps, sample_frac = 1) {
self$n_timesteps n_timesteps
self$x torch_tensor((x - train_mean) / train_sd)
n length(self$x) - self$n_timesteps - 1
self$starts sort(sample.int(
n = n,
size = n * sample_frac
))
},
.getitem = function(i) {
start self$starts[i]
end start + self$n_timesteps - 1
lag 1
list(
x = self$x[start:end],
y = self$x[(start+lag):(end+lag)]$squeeze(2)
)
},
.length = function() {
length(self$starts)
}
)Dataset as well as dataloader instantations then can proceed as before.
batch_size 32
train_ds elec_dataset(elec_train, n_timesteps, sample_frac = 0.5)
train_dl train_ds %>% dataloader(batch_size = batch_size, shuffle = TRUE)
valid_ds elec_dataset(elec_valid, n_timesteps, sample_frac = 0.5)
valid_dl valid_ds %>% dataloader(batch_size = batch_size)
test_ds elec_dataset(elec_test, n_timesteps)
test_dl test_ds %>% dataloader(batch_size = 1)Technically, the model consists of three modules: the aforementioned encoder and decoder, and the seq2seq module that orchestrates them.
Encoder
The encoder takes its input and runs it through an RNN. Of the two things returned by a recurrent neural network, outputs and state, so far we’ve only been using output. This time, we do the opposite: We throw away the outputs, and only return the state.
If the RNN in question is a GRU (and assuming that of the outputs, we take just the final time step, which is what we’ve been doing throughout), there really is no difference: The final state equals the final output. If it’s an LSTM, however, there is a second kind of state, the “cell state”. In that case, returning the state instead of the final output will carry more information.
encoder_module nn_module(
initialize = function(type, input_size, hidden_size, num_layers = 1, dropout = 0) {
self$type type
self$rnn if (self$type == "gru") {
nn_gru(
input_size = input_size,
hidden_size = hidden_size,
num_layers = num_layers,
dropout = dropout,
batch_first = TRUE
)
} else {
nn_lstm(
input_size = input_size,
hidden_size = hidden_size,
num_layers = num_layers,
dropout = dropout,
batch_first = TRUE
)
}
},
forward = function(x) {
x self$rnn(x)
# return last states for all layers
# per layer, a single tensor for GRU, a list of 2 tensors for LSTM
x x[[2]]
x
}
)Decoder
In the decoder, just like in the encoder, the main component is an RNN. In contrast to previously-shown architectures, though, it does not just return a prediction. It also reports back the RNN’s final state.
decoder_module nn_module(
initialize = function(type, input_size, hidden_size, num_layers = 1) {
self$type type
self$rnn if (self$type == "gru") {
nn_gru(
input_size = input_size,
hidden_size = hidden_size,
num_layers = num_layers,
batch_first = TRUE
)
} else {
nn_lstm(
input_size = input_size,
hidden_size = hidden_size,
num_layers = num_layers,
batch_first = TRUE
)
}
self$linear nn_linear(hidden_size, 1)
},
forward = function(x, state) {
# input to forward:
# x is (batch_size, 1, 1)
# state is (1, batch_size, hidden_size)
x self$rnn(x, state)
# break up RNN return values
# output is (batch_size, 1, hidden_size)
# next_hidden is
c(output, next_hidden) % x
output output$squeeze(2)
output self$linear(output)
list(output, next_hidden)
}
)seq2seq module
seq2seq is where the action happens. The plan is to encode once, then call the decoder in a loop.
If you look back to decoder forward(), you see that it takes two arguments: x and state.
Depending on the context, x corresponds to one of three things: final input, preceding prediction, or prior ground truth.
-
The very first time the decoder is called on an input sequence,
xmaps to the final input value. This is different from a task like machine translation, where you would pass in a start token. With time series, though, we’d like to continue where the actual measurements stop. -
In further calls, we want the decoder to continue from its most recent prediction. It is only logical, thus, to pass back the preceding forecast.
-
That said, in NLP a technique called “teacher forcing” is commonly used to speed up training. With teacher forcing, instead of the forecast we pass the actual ground truth, the thing the decoder should have predicted. We do that only in a configurable fraction of cases, and – naturally – only while training. The rationale behind this technique is that without this form of re-calibration, consecutive prediction errors can quickly erase any remaining signal.
state, too, is polyvalent. But here, there are just two possibilities: encoder state and decoder state.
-
The first time the decoder is called, it is “seeded” with the final state from the encoder. Note how this is the only time we make use of the encoding.
-
From then on, the decoder’s own previous state will be passed. Remember how it returns two values, forecast and state?
seq2seq_module nn_module(
initialize = function(type, input_size, hidden_size, n_forecast, num_layers = 1, encoder_dropout = 0) {
self$encoder encoder_module(type = type, input_size = input_size,
hidden_size = hidden_size, num_layers, encoder_dropout)
self$decoder decoder_module(type = type, input_size = input_size,
hidden_size = hidden_size, num_layers)
self$n_forecast n_forecast
},
forward = function(x, y, teacher_forcing_ratio) {
# prepare empty output
outputs torch_zeros(dim(x)[1], self$n_forecast)$to(device = device)
# encode current input sequence
hidden self$encoder(x)
# prime decoder with final input value and hidden state from the encoder
out self$decoder(x[ , n_timesteps, , drop = FALSE], hidden)
# decompose into predictions and decoder state
# pred is (batch_size, 1)
# state is (1, batch_size, hidden_size)
c(pred, state) % out
# store first prediction
outputs[ , 1] pred$squeeze(2)
# iterate to generate remaining forecasts
for (t in 2:self$n_forecast) {
# call decoder on either ground truth or previous prediction, plus previous decoder state
teacher_forcing runif(1) teacher_forcing_ratio
input if (teacher_forcing == TRUE) y[ , t - 1, drop = FALSE] else pred
input input$unsqueeze(3)
out self$decoder(input, state)
# again, decompose decoder return values
c(pred, state) % out
# and store current prediction
outputs[ , t] pred$squeeze(2)
}
outputs
}
)
net seq2seq_module("gru", input_size = 1, hidden_size = 32, n_forecast = n_forecast)
# training RNNs on the GPU currently prints a warning that may clutter
# the console
# see
# alternatively, use
# device
device torch_device(if (cuda_is_available()) "cuda" else "cpu")
net net$to(device = device)The training procedure is mainly unchanged. We do, however, need to decide about teacher_forcing_ratio, the proportion of input sequences we want to perform re-calibration on. In valid_batch(), this should always be 0, while in train_batch(), it’s up to us (or rather, experimentation). Here, we set it to 0.3.
optimizer optim_adam(net$parameters, lr = 0.001)
num_epochs 50
train_batch function(b, teacher_forcing_ratio) {
optimizer$zero_grad()
output net(b$x$to(device = device), b$y$to(device = device), teacher_forcing_ratio)
target b$y$to(device = device)
loss nnf_mse_loss(output, target)
loss$backward()
optimizer$step()
loss$item()
}
valid_batch function(b, teacher_forcing_ratio = 0) {
output net(b$x$to(device = device), b$y$to(device = device), teacher_forcing_ratio)
target b$y$to(device = device)
loss nnf_mse_loss(output, target)
loss$item()
}
for (epoch in 1:num_epochs) {
net$train()
train_loss c()
coro::loop(for (b in train_dl) {
loss train_batch(b, teacher_forcing_ratio = 0.3)
train_loss c(train_loss, loss)
})
cat(sprintf("\nEpoch %d, training: loss: %3.5f \n", epoch, mean(train_loss)))
net$eval()
valid_loss c()
coro::loop(for (b in valid_dl) {
loss valid_batch(b)
valid_loss c(valid_loss, loss)
})
cat(sprintf("\nEpoch %d, validation: loss: %3.5f \n", epoch, mean(valid_loss)))
}Epoch 1, training: loss: 0.37961
Epoch 1, validation: loss: 1.10699
Epoch 2, training: loss: 0.19355
Epoch 2, validation: loss: 1.26462
# ...
# ...
Epoch 49, training: loss: 0.03233
Epoch 49, validation: loss: 0.62286
Epoch 50, training: loss: 0.03091
Epoch 50, validation: loss: 0.54457It’s interesting to compare performances for different settings of teacher_forcing_ratio. With a setting of 0.5, training loss decreases a lot more slowly; the opposite is seen with a setting of 0. Validation loss, however, is not affected significantly.
The code to inspect test-set forecasts is unchanged.
net$eval()
test_preds vector(mode = "list", length = length(test_dl))
i 1
coro::loop(for (b in test_dl) {
output net(b$x$to(device = device), b$y$to(device = device), teacher_forcing_ratio = 0)
preds as.numeric(output)
test_preds[[i]] preds
i i + 1
})
vic_elec_jan_2014 vic_elec %>%
filter(year(Date) == 2014, month(Date) == 1)
test_pred1 test_preds[[1]]
test_pred1 c(rep(NA, n_timesteps), test_pred1, rep(NA, nrow(vic_elec_jan_2014) - n_timesteps - n_forecast))
test_pred2 test_preds[[408]]
test_pred2 c(rep(NA, n_timesteps + 407), test_pred2, rep(NA, nrow(vic_elec_jan_2014) - 407 - n_timesteps - n_forecast))
test_pred3 test_preds[[817]]
test_pred3 c(rep(NA, nrow(vic_elec_jan_2014) - n_forecast), test_pred3)
preds_ts vic_elec_jan_2014 %>%
select(Demand) %>%
add_column(
mlp_ex_1 = test_pred1 * train_sd + train_mean,
mlp_ex_2 = test_pred2 * train_sd + train_mean,
mlp_ex_3 = test_pred3 * train_sd + train_mean) %>%
pivot_longer(-Time) %>%
update_tsibble(key = name)
preds_ts %>%
autoplot() +
scale_colour_manual(values = c("#08c5d1", "#00353f", "#ffbf66", "#d46f4d")) +
theme_minimal()
Figure 1: One-week-ahead predictions for January, 2014.
Comparing this to the forecast obtained from last time’s RNN-MLP combo, we don’t see much of a difference. Is this surprising? To me it is. If asked to speculate about the reason, I would probably say this: In all of the architectures we’ve used so far, the main carrier of information has been the final hidden state of the RNN (one and only RNN in the two previous setups, encoder RNN in this one). It will be interesting to see what happens in the last part of this series, when we augment the encoder-decoder architecture by attention.
Thanks for reading!
